Aerohive HiveAP 120 Access Point Network Router – [AuStock]

Description

Description:

The Aerohive Networks HiveAP 120 is a high-performance; 802.11n; 2×2 MIMO access point with a 10/100/1000 Ethernet port that delivers a data rate of 600Mbps with dual radios.

The HiveAP 120 is cost-effective; enterprise-grade solution – ideal for education; health care; and distributed enterprise environments.

With two radios and the ability to provide service concurrently on both 2.4GHz and 5GHz bands; the HiveAP 120 provides top performance at a low price point.

The HiveAP 120 provides both mesh and access for 802.11a; b; g and n clients; with Aerohive’s unique and resilient cooperative control architecture.

Specifications:

Radio Specifications – 802.11a

• 5.150 – 5.850 GHz Operating Frequency
• Orthogonal Frequency Division Multiplexing (OFDM) Modulation
• 24 dBm Transmit Power
• Rates (Mbps): 54, 48, 36, 24, 18, 12, 9, 6 w/ auto fallback

Radio Specifications – 802.11b

• 2.4 – 2.5 GHz Operating Frequency
• Direct-Sequence Spread-Spectrum (DSSS) Modulation
• 20 dBm Transmit Power
• Rates (Mbps): 11, 5.5, 2, 1 w/ auto fallback

Radio Specifications – 802.11g

• 2.4 – 2.5 GHz Operating Frequency
• Orthogonal Frequency Division Multiplexing (OFDM) Modulation
• 22 dBm (100 mW) Transmit Power
• Rates (Mbps): 54, 48, 36, 24, 18, 12, 9, 6 w/ auto fallback
• A-MPDU and A-MSDU Frame Aggregation

Radio Specifications – 802.11n

• 2.4 – 2.5 GHz & 5.150 – 5.950 GHz Operating Frequency
• 802.11n Modulation
• 24 dBm Transmit Power
• Rates (Mbps): MCS0 – MCS15 (6.5Mbps – 300Mbps)
• 2×2 Multiple-In, Multiple-Out (MIMO) Radio
• HT20 and HT40 High-Throughput (HT) Support
• A-MPDU and A-MSDU Frame Aggregation

Receive Sensitivity – At Highest DataRate

• 802.11b: -87 dBm
• 802.11g: -76 dBm
• 802.11n (2.4) @ 20 MHz: -73 dBm
• 802.11n (2.4) @ 40 MHz: -71 dBm
• 802.11a: -75 dBm
• 802.11n (5) @ 20 MHz: -73 dBm
• 802.11n (5) @ 40 MHz: -70 dBm

Antennas

• 2 x Integrated single band, 2.4-2.5 GHz Omni-directional, 4.0 dBi gain
• 2 x Integrated single band, 5.1-5.8 GHz Omni-directional, 2.0 dBi gain

Interfaces

• Autosensing 10/100/1000 Base-T Ethernet Port
• Power over Ethernet (PoE) capable (802.3af) Ethernet Port
• 1x Reset Pinhole

Power Options

• 802.3af Power over Ethernet (PoE) port
• 48v DC external power adapter (sold separately)

Power Specification

• AC/DC power adapter:
  • Input: 100–240 VAC
  • Output: 48 V/0.625 A
• PoE nominal input voltages: 48 V, 0.35A (802.3af)
• Typical power consumption: 8W
• RJ-45 power input pins: Wires 4, 5, 7, 8 or 1, 2, 3, 6

NOTE:

• This item is pre-owned. Might have few minor scratches. Perfect working.
• The power adapter is NOT included.
